Reach-in temperature humidity chamber can accurately simulate a wide range of complicated natural environmental conditions such as heat damp, low temperature, high temperature, constant heat, etc. and is suitable for reliability test in industrial products.
Model No. | KMH-270S |
Inner Dimensions W×H×D（mm） | 700×700×550 |
External Dimensions W×H×D（mm） | 900×1663×1540 |
Area | About 1.386㎡ |
Temperature Range | -70℃ to 150℃ |
Heating Rate | -70℃ ~ +150℃, average 3℃/min (with no load) |
Cooling Rate | +150℃ ~ -70℃ , average 1~3℃/min (with no load) |
Humidity Range | 20% ~ 98% R.H |
Temperature&Humidity Fluctuation | ±0.5°C/±2.0% RH |
Temperature & Humidity Uniformity | ≤ 2.0°C/3% RH |
Maximum Machine Power | About 8KW |
Maximum Working Current | About 18A |
