Dust Test Chamber KM-SC-1500
Dust Test Chamber KM-SC-1500
- IP5X
- IP6X
- Sand and dust test chamber
- Programmable Controllers
- Solid structure
- Various sizes available
- Color touch screen
- Observation window
Description
Specification
Video
Description
Application of Dust Test Chamber
Dust test chamber simulates the natural wind and sand climate, exposing the product to dry dust or dust-filled environment to test the resistance and operation of the product under wind and sand climate conditions, and to evaluate the sealing of the product shell.
Dust test chamber application areas: automotive, lighting, low-voltage electrical appliances, communications, motors, instruments, household appliances, etc.
Features of Dust Test Chamber
- Circulating air duct with heater to avoid dust condensation.
- Quadruple vacuum equipment to maintain vacuum state and improve cycle efficiency.
- Multiple protection systems to ensure safe use.
- Large observation window design, convenient to observe the test status.
Specification
Model Number | KM-SC-408 | KM-SC-800 | KM-SC-1000 | KM-SC-1500 |
Inner Dimensions W×H×D (mm) | 700×750×800 | 1000×1000×800 | 1000×1000×1000 | 1000×1000×1500 |
Cable Port | Φ5 | |||
Observation Window | 460×560 | |||
Temperature Range | RT+10 ~ 40℃ | |||
Dust Control Method | Powder spraying or free dust fall | |||
Test Time | 0-999h | |||
Vacuum Degree | 0-10Kpa | |||
Pumping Speed | 0-4800L/h | |||
Controller | Programmable controller | |||
Power | 380V, 1.5KW | |||
Site Size | ≥180×180cm | |||
Dust | Talcum Powder | |||
Video
