Vacuum Oven KUO-64
Vacuum Oven KUO-64
- Safety protection devices
- Altitude test chamber
- 64L Volume
- Equipped with manual inflation valve
- Accept temperature and size customization
- Color touch screen
- Stainless steel plate
- Single door
- Maximum Temp. 300°C
Description
Specification
Video
Description
Application of Vacuum Oven
The 64L vacuum oven can be used for vacuum drying and low-pressure environment adaptability test. Vacuum drying is mainly suitable for battery cores. Low pressure testing is suitable for materials that need to be stored and used in high altitude environments, such as aircraft products.
Features of Vacuum Oven
- One-piece design, saving space.
- Small pressure tolerance to ensure accurate test data.
- Temperature, pressure, size can be customized.
- High quality material, long service life.
- Phase sequence protection, phase loss protection, leakage protection, overload short circuit protection.
Specification
Model | KUO-64 |
Inner Dimensions W×H×D（mm） | 400×400×400 |
External Dimensions W×H×D（mm） | 550×950×1000 |
Volume | 64L |
Pressure Range | Normal Pressure ~ 18.8kPa |
Depressurization Rate | Normal pressure ~ 75.2kPa(2438m) ≤10m/s 75.2 ~ 18.8kPa≤15s (room temp, empty) |
Pressure Deviation | ≤±2kPa(≥40kPa), ≤±5kPa(2 ~40kPa) |
Load | ≤10kg |
Noise | ≤70dB |
Power | 380V AC(±10%)50Hz±1Hz |
